fixLink® Pro RJ45 Keystone Module Cat. 6A ISO/IEC

Mounting - RJ45 fixLink® Pro Keystone Modul

If you would like to watch our YouTube video, please activate the “Marketing” option in the cookie consent section of our privacy policy.

Change consent

alternatively watch video on YouTube

The fixLink^® Pro RJ45 keystone module has become even easier to install than the fixLink® SL. The new module provides the user with an optimised RJ45 socket module of the highest quality for the transmission of 10Gbit Ethernet. The fixLink^® Pro RJ45 keystone module can be assembled in under a minute using a side cutter. The freely accessible contact zone ensures perfect assembly quality and thus reliable transmission performance. The 360° shield removal is automatically ensured when the module is closed. The special contact geometry in conjunction with a 30 μ inch gold plating ensures 4PPoE in accordance with IEEE 802.3bt under all conditions. The housing material consists of nickel-plated die-cast zinc and therefore fulfils the highest environmental and mechanical requirements. In conjunction with the design-capable module holder, it can be combined with all standard switch programmes. Certifications from independent test laboratories round off the highest quality standards of the fixLink® Pro Keystone module. It is supplied in environmentally friendly cardboard packaging.
Connector standard IEC 60603-7-51.

Mechanical properties:

Mating cycles ≥ 750
Material Housing Zinc die-cast nickel-plated
Integrated dust cover Plastic, transparent, interchangeable with other colours
Gold plating in the contact area 30 µ inch
Suitable for cable diameters 5-9 mm
Tool-free wiring optionally according to T568A and T568B

Environmental requirements:

Connection class IP20
Temperature range -40°C to +70°C

Electrical properties:

Contact resistance ≤ 20 mΩ
Insulation resistance between the contacts ≥ 500 MΩ
Dielectric strength contact - contact 1000 V DC/AC peak
Dielectric strength contact - shield 1500 V DC/AC peak
Current carrying capacity at 50 °C 1.25 A
Suitable for 4PPoE according to IEEE 802.3bt

Transmission properties:

Ideally suited for the transmission of 10 Gbit Ethernet (10GBASE-T) in accordance with IEEE 802.3an and for applications up to 500 MHz in accordance with Cat. 6A and Class EA ISO/IEC 11 801 AMD1/2, DIN EN 50173-1, link length > 2 m
Certified by GHMT according to Cat. 6A ISO/IEC (PvP) component performance

Description

Order Code

PU 24

Order Code

Single packaging

fixLink^® Pro RJ45 KeystoneModule Cat. 6A ISO/IEC AWG 24-22

CKFAK002

CKFAK002EP

fixLink^® Pro RJ45 Keystone Module Cat. 6A ISO/IEC AWG 27-26

CKFAKFL2

CKFAKFL2EP

fixLink® SL RJ45 Keystone Module shielded Cat. 6A ISO/IEC

EasyLan® RJ45 fixLink Keystone Modul Kat. 6A ISO/IEC Installation

If you would like to watch our YouTube video, please activate the “Marketing” option in the cookie consent section of our privacy policy.

Change consent

alternatively watch video on YouTube

EasyLan® RJ45 fixLink Keystone Modul Kat. 6A ISO/IEC Removal

If you would like to watch our YouTube video, please activate the “Marketing” option in the cookie consent section of our privacy policy.

Change consent

alternatively watch video on YouTube

With the fixLink^® SL RJ45 Keystone module, the user receives an RJ45 socket module of the highest quality. The fixLink^® SL RJ45 keystone module can be assembled in less than a minute using a side cutter. The freely accessible contact zone ensures perfect assembly quality and thus reliable transmission performance. The integrated wedge is simply snapped into place for 360° shield removal, eliminating the time-consuming attachment of a cable tie. The special contact geometry in conjunction with a 30 μ inch gold plating ensures 4PPoE in accordance with IEEE 802.3bt under all conditions. The housing material consists of nickel-plated die-cast zinc and therefore fulfils the highest environmental and mechanical requirements. In conjunction with the design-capable module holder, it can be combined with all standard switch programmes. Various certifications from independent test laboratories round off the highest quality standards of the fixLink® SL Keystone module. They are supplied in environmentally friendly cardboard packaging. The module can be ordered in the versions AWG 24-22 for installation cables and AWG 27-26 for flexible cables (patch cables).
Connector standard IEC 60603-7-51.
